LogicDrawer is completely free and open-source. It has AI assistant which allows you to create circuits just bu describing. It can parse SystemVerilog code and turn them into functional circuits. You can draw logic circuits to paper by hand and upload the photo to detect model, and it can create a digital version of your circuit completely for free. You can open up accounts for saving your circuits to cloud for later access. It has clean UI with many components and it is improved all the time.see more
Founder
Screenshots
About
Imagine designing complex digital logic circuits without getting bogged down in tedious manual drawing or complicated syntax. That is the power unlocked by LogicDrawer, a revolutionary, completely free, and open-source logic circuit simulator designed for everyone from students learning the fundamentals to seasoned engineers prototyping advanced systems. What truly sets LogicDrawer apart is the integration of its intelligent AI assistant. Forget spending hours painstakingly placing gates and wires; you can now simply describe the circuit you envision—perhaps something like 'a 4-bit adder with carry-in'—and watch as the AI translates your natural language into a functional, editable digital schematic. This capability dramatically accelerates the design cycle, allowing you to focus purely on the logic and functionality rather than the mechanics of the drawing tool itself. Furthermore, if you have existing designs sketched out on paper, LogicDrawer offers an almost magical solution: upload a photo of your handwritten schematic, and the system uses advanced image recognition to detect the components and instantly convert your physical sketch into a precise, editable digital model. This bridges the gap between analog ideation and digital realization seamlessly.
LogicDrawer is built not just for creation but for collaboration and longevity. Because it is entirely open-source, the community constantly improves its clean, intuitive user interface and expands its library of available components, ensuring you always have access to the latest tools and optimizations. For those working on professional or long-term projects, the option to create cloud accounts means your valuable circuit designs are safely stored and accessible from anywhere, anytime. Beyond simple drag-and-drop, the tool boasts advanced parsing capabilities, allowing you to input existing SystemVerilog code and have LogicDrawer reverse-engineer it back into a visual, functional circuit diagram. This is invaluable for documentation, debugging legacy designs, or understanding complex hardware description language implementations at a glance. Whether you are simulating basic AND gates, designing complex microprocessors, or simply trying to visualize Boolean algebra in action, LogicDrawer provides a robust, accessible, and incredibly intelligent platform to bring your digital ideas to life, all without ever opening your wallet.
